Honda Super Cub 110

The pushrod overhead valve (OHV) air-cooled four-stroke single cylinder engine had a 40-by-39-millimetre (1.6 in × 1.5 in) bore × stroke, displacing 49 cubic centimetres (3.0 cu in), and could produce 3.4 kilowatts (4.5 hp) at 9,500 rpm, for maximum speed of 69 km/h (43 mph), under favorable conditions. The low compression ratio meant the engine could consume inexpensive and commonly available low octane fuel, as well as minimizing the effort to kick start the engine, making the extra weight and expense of an electric starter an unnecessary creature comfort. Though some of the many Super Cub variations came with both kick and electric start, the majority sold well without it. Even the latest 2011 model year Japanese domestic market (JDM) Super Cub 50 and Super Cub 110 versions, with modern technology and conveniences like fuel injection and a fuel gauge, were not offered with an electric start option. The sequential-shifting three- or four-speed gearbox was manually shifted, but clutchless, without the need for a clutch lever control, using instead a centrifugal clutch along with a plate clutch slaved to the foot-shift lever to engage and disengage the gearbox from the engine. While not intuitive to learn, once the rider got used to it, the semi-automatic transmission, "took the terror out of motorcycling" for novice riders. Unlike many scooters CVTs, the centrifugal clutch made it possible to push start the Super Cub, a useful advantage if the need arose. The early Super Cubs used a 6 volt ignition magneto mounted on the flywheel, with a battery to help maintain power to the lights, while later ones were upgraded to capacitor discharge ignition (CDI) systems. The lubrication system did not use an oil pump or oil filter, but was a primitive splash-fed system for both the crankcase and gearbox, with a non-consumable screen strainer to collect debris in the engine oil. Both the front and rear brakes were drums. On both the front and rear wheels were 2.25" × 17" wire spoke wheels, with full-width hubs. Honda recommended daily checks of the lights, horn, tire pressure, brakes, fuel and oil level, and a weekly check of the battery electrolyte level. The new engine break-in maintenance was done at 320 kilometres (200 mi), requiring adjustment of the valve tappets and contact breaker points, and an oil change, and the rider was advised to stay under 48 kilometres per hour (30 mph) for the first 800 kilometres (500 mi). Every 1,600 kilometres (1,000 mi) the spark plug needed cleaning, and the chain adjustment checked, and every 3,200 kilometres (2,000 mi) an oil change, breaker point check, and valve adjustment was due. At 8,000 kilometres (5,000 mi), major maintenance was due, requiring the removal and cleaning of the carburetor, drive chain, exhaust silencer, and wheel bearings. The rider closed a manual choke to aid in starting at cold temperatures. By the standards of the day, this was a simple motorcycle, with minimal maintenance demands, and it earned a reputation for high reliability.
